Model
Brand LSI
Model LSI00200 (9240-8i Single)
Form Factor Low Profile
Details
Type SATA / SAS
Internal Connectors 2 x SFF-8087 mini-SAS
Interface PCI-Express 2.0 x8
Transfer Rate Up to 6Gb/s
RAID RAID 0/1/5/10/50 JBOD
Dimensions 6.6" x 2.536"
Features
SAS Controller: LSI SAS2008
Key RAID Data Protection:
RAID levels 0, 1, 5, 10, 50 and JBOD mode
Selectable logical drive as boot drive
Consistency Check
Fast initialization for quick array setup
Native Command Queuing
Staggered spin up for SATA drives
Hot plug support
Global hot spare support
Online Capacity Expansion (OCE)
Online RAID Level Migration (RLM)
Single controller Multipathing
I/O Load balancing
SSD support with SSD Guard
Automatic rebuild of hot spare drives
Auto resume during array rebuild
Fault LED support through SGPIO
>2TB logical drive support
Soft bad block management
Error recovery support
DDF compliant Configuration on Disk
S.M.A.R.T. support
Patrol read for media scanning and repairing
Enclosure management:
-SES (inband)
-SGPIO (sideband)
RAID Management:
MegaRAID Management Suite:
MegaRAID Storage Manager
MegaCLI (command-line interface)
WebBIOS.
Package Contents
MegaRAID SAS 9240-8i QIG
LP bracket Driver & Manual CD
